EI-5030A X-Ray Security Inspection Equipment
Product Instruction
Product Instruction Eastimage is an industry-leading provider of security inspection products and security solutions. Established in 2003, the company has 50,000 square meters of independent property rights of the production base. After more than 20 years of development, Eastimage has become a major supplier and a leading R&D and manufacturing base for security products in China.
The EI-5030A X-ray security inspection equipment is mainly designed with the core of convenience .Its smart appearance, on-site mobility and temporary adjustment become more popular among end users.
Parameters
Penetration (Steel): ≥6mm
Wire Resolution: 0.101mm (38AWG) (Standard) /0.0787mm (40AWG) (high-performance model)
Monitor: 22''LED with a resolution of 1920*1080
Standard Load: 50kg (customizable for larger loads)
Software Function
Image Processing: Black/White, Inverse color, High/Low Penetration, Inorganic/Organic stripping, Super enhancement, Variable absorption, Pseudo-color, etc.
One-Click Image Processing: Customizable function keys for quick image processing based on user needs.
Image Zoom: Up to 64X dynamic continuous zoom & panning for any area.
Fault Indication: Self-diagnostic function, faults alarm,easy troubleshooting.
Explosive/High-Density Alarm: Suspected explosives/High absorption material in the package can be sound and light alarmed.
Image Recall: Supports unlimited image recall, up to the first image from the current startup session.
Image Storage: 500,000 images storage, with traceability for images from the past 90 days.
Application Area
Technical Data
Tunnel Size: 505mm(W)×305mm(H)
Conveyor Speed 0.2m/s
Noise <65dB(A)
Standard Function
One key on/off: Through one key of Keyboard to realise power on automatically entering the interface & power off peripheral accessories.
TIP System: TIP can self-add dangerous items’image,report the results of threat items marked by the operator,reminding the supervision.
OTP System: The Operator Training Program System,using system pre-stored package images to train operator.
User Management Multi-level user administrators, maintainers, and operators manage different rights and customize user rights.
Optional Function
EI-BB100 BlackBox: Real-time monitoring baggage pass in/out, vedio record whole procedure of the X-ray baggage image scan & baggage passing.
Bi-directional Scanning: Either end can be placed into the package to achieve X-ray image scanning, more practical on-site.
Energy Saving: The conveyor will auto stop after 90s without baggage on and it will auto running when baggage on without other operation.
6 pseudo Color: Image 6 pseudo-Color.
Auxiliary Image Recognition: Automatically identify and calibrate the name of the inspected items, and provide the basis for auxiliary drawing recognition.
Multi-speed adjustment: Conveying system can be switched between 0.2m/s, 0.3m/s and 0.4m/s to improve the passing efficiency.
NI(network interface): Off-site real-time viewing of overpack images and data, and remote control of equipment. Image.
Print Prints: on-screen images at any time.
Other Function: UPS uninterruptible power supply, voltage stabilized power supply, LED security reminder.
X-Ray Generator
Anode Voltage: 80KV(adjustable)
Cooling & Running: Cycle Sealed oil cooling &100%
Installation Data
Weight: 185kg
Work Temperature/Humidity: 0℃～45℃／10%～95% (non-condensing)
Store Temperature/Humidity: -40℃～60℃／10%～95% (non-condensing)
Power Supply: 110VAC-240VAC，50/60Hz
Power Consumption: About 0.37 kVA
X-Ray Security
X-ray leakage dose rate: <1μGy/h (5cm distance from outer)Compliance with all international and national health and safety standards
Film Safety: Film safety according to ASA/ISO1600 standard
