EI-6550DV Dual View X-ray Baggage Scanner Machine for Security
Product Instruction
EI-6550DV X-ray baggage scanner machine is a kind of new dual view x-ray security inspection equipment from EASTIMAGE. It can display horizontal and vertical images by two independent generators, and can quickly detect organic, inorganic, mixtures or light metals according to the effective atomic number of detected objects, which can identify overlapping articles and contraband easily and precisely.
EI-6550DV x-ray machine with the special tunnel size of 65cm W x50cm H, which is a suitable size for baggage checking in airport, railway systems, military base, government facilities, commercial facilities etc. This X-ray baggage scanner show high resolution x-ray screening images of bags, to see clearly if any threat hiden inside. Also equiped with self identification function to identify the high density materials, possible explosives and drugs etc.
The latest function for this model can self identify most kind of the threats and show the name of the threats on the image to alert the operator. Beside this function, hiden cameras on the x-ray scanner machine can show the videos of the baggages and passengers like a mini cctv camera for security.
Technology Features
● Dual view design; display horizontal and vertical images simultaneously;identify overlapping articles and contraband easily and precisely.
● New x-ray protection technology
● Multi-functions image processing system
● EI-TIP( Threat Image Projection) function
● Shiny clear images
● Any selection of the image magnified area
● Collection the high-speed parallel of detection data
● Removable split structure with independent console
● Medium tunnel design with multi-functions operator interface
● Support JPG&BMP image transformation format to USB
Applications
Public Entertainment Places, Public Security System, Conference Center, Tourist Places, Government Office, Border Crossing
General Specifications
Tunnel Size:650 mm(W)×526 mm(H)
Generator numbers: 2 generators both vertical & Horizonal
Conveyor Speed:0.2m/s
Conveyor Height:691mm
Max. Load:160 kg(Evenly distributed)
System Noise:<65dB(A)
Image Resolution:22''LCD 1920×1080
Installation Data
Size /weight:2342mm(L)x 1273 mm(W)x 1371 mm(H)/800KG
Working Temperature / Humidity:0℃~+ 45℃/10%~95% (non-condensing)
Storage Temperature / Humidity:- 40℃~+ 60℃/10%~95% (non-condensing)
Power Supply:AC 220 V(+10%~-15%) 50±3(Hz)
Power Consumption:About 0.50(KVA)
Optional Features
High Density Area Alarm, Black Box, TIP Threat Image Projection, OTP Operator Training Program, One Key To Shutdown, Environment Protection and Energy Saving.
Software including:
*x-ray scanner software
*OTP(Operator Training Programe)
*TIP(Threat Images Projection)
*X-Auto sight(Threat self identification assistant function)
*Guns,Knives, Explosives, Drugs general finder
Other optional parts available:
* Entrance & Exit tables/ Roller Tables.
* UPS
* Stabilizer
* BB100 camera video system
* Energy saving function
Kind note : If you have any questions about X-ray baggage scanners products, please contact our online support or email us, we are glad to give professional advice for your needs.
